Model KR 18

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight

2 – 4 t 4.4K – 8.8K lb
Rated power

18 kW 24 hp (18 kW)
Drum cutter length (A)

628 mm 24 in
Cutter head width (B)

425 mm 16 in
Cutter drum diameter (C)

225 mm 9 in
Recommended rotation speed

100 rpm 100 rpm
Recommended oil flow

25 – 40 l/min 7 – 11 gal/min
Max. oil flow at 10 bar

60 l/min 16 gal/min
Max. operating hydraulic pressure

400 bar 5,800 psi (400 bar)
Max. torque at 380 bar

2,000 Nm 1,500 lbf·ft
Max. cutting force at 380 bar

17.8 kN 4,000 lbf
Weight

155 kg 340 lb
Pick box

PH 14 Type PH 14 Type
Number of picks

44 Pcs 44 Pcs
Standard pick

ER 15/29/26/14 C ER 15/29/26/14 C
