Model KR 160

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight

35 – 55 t 77K – 121K lb
Rated power

160 kW 214 hp (160 kW)
Drum cutter length (A)

1.596 mm 62 in
Cutter head width (B)

1.050 mm 41 in
Cutter drum diameter (C)

718 mm 28 in
Max. torque at 380 bar

36.400 Nm 26,900 lbf·ft
Max. cutting force at 380 bar

101.393 kN 24,100 lbf
Recommended rotation speed

65 rpm 65 rpm
Recommended oil flow

300 – 390 l/min 80 – 104 gal/min
Max. oil flow at 10 bar

400 l/min 106 gal/min
Max. operating hydraulic pressure

400 bar 5,800 psi (400 bar)
Weight

2.500 kg 5,600 lb
Pick box

PH 32 HD Type PH 32 HD Type
Number of picks

56 Pcs 56 Pcs
Standard pick

ER 19/75/70/30 Q ER 19/75/70/30 Q
