KRC Bullhead Cutters

Model KRC 140

TECHNICAL DATA

3D MODEL

VIDEO

FOTOS

Measure:

Recommended excavator weight

25 – 40 t 55,000 – 88,000 lb
Rated power

140 kW 188 hp (140 kW)
Drum cutter length (A)

1.520 mm 60 in
Cutter head width (B)

880 mm 35 in
Cutter drum diameter (C)

700 mm 28 in
Recommended rotation speed

65 rpm 65 rpm
Recommended oil flow

250 – 320 l/min 66 – 85 gal/min
Max. oil flow at 10 bar

380 l/min 100 gal/min
Max. operating hydraulic pressure

400 bar 5,800 psi (400 bar)
Max. torque at 380 bar

25,400 Nm 18,730 lbf·ft
Max. cutting force at 380 bar

72.6 kN 16,320 lbf
Max. uniaxial compressive strength

100 MPa 15,000
Weight

1.950 kg 4,300 lb
Pick box

PH 32 HD Type PH 32 HD Type
Number of picks

52 Pcs 52 Pcs
Standard pick

ER 17/75/70/30 Q ER 17/75/70/30 Q
