KDS Diamond Saws

Model KDS 20

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight

2 – 4 t 4,400 – 8,800 lb
Rated power

55 kW 74 hp (55 kW)
Max. saw blade diameter (A)

800 mm 32 in
Max. torque at 350 bar

140 Nm 104 lbf·ft
Max. rotation speed

1.200 rpm 1,200 rpm
Max. oil flow

40 l/min 10 gal/min
Max. operating hydraulic pressure

350 bar 5,000 psi (350 bar)
Weight of drive unit excl. saw blade and protective cover

100 kg 220 lb
