EX Patch Planers

Model EX 45 HD

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight
10 – 16 t 22,000 – 35,000 lb
Rated power
65 kW 88 hp (65 kW)
Cutting width, standard (A)
450 mm 18 in
Cutting depth, adjustable (B)
0 – 150 mm 0 – 6 in
Recommended rotation speed
70 – 110 rpm 70 – 110 rpm
Recommended oil flow at 100 bar
110 – 170 l/min 29 – 44 gal/min
Min. oil flow
100 l/min 27 gal/min
Max. oil flow
180 l/min 48 gal/min
Max. operating hydraulic pressure
380 bar 5,500 psi (380 bar)
Torque at 350 bar
8,700 Nm 6,500 lbf·ft
Cutting force at 350 bar
30 kN 6,750 lbf
Operating weight
730 kg 1,610 lb
Pick box
PH 20 Type PH 20 Type
Number of picks
49 Pcs 49 Pcs
Standard pick
ER 16/48/32/20 H ER 16/48/32/20 H
