EK Chain Cutters

Model EK 150

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight

35 – 50 t 77,000 – 110,000 lb
Rated power

150 kW 200 hp (150 kW)
Drum cutter length (A)

2.150 mm 85 in
Cutter head width (B)

800 | 900 | 1.000 mm 32 | 35 | 40 in
Cutter drum diameter (C)

850 mm 34 in
Width of gearbox (D)

700 mm 28 in
Recommended rotation speed

60 rpm 60 rpm
Recommended oil flow

280 – 320 l/min 74 – 85 gal/min
Max. oil flow

450 l/min 118 gal/min
Max. operating hydraulic pressure

400 bar 5,800 psi (400 bar)
Max. torque at max. hydraulic pressure

31,300 Nm 22,350 lbf·ft
Max. cutting force at max. torque

71.3 kN 16,030 lbf
Max. uniaxial compressive strength

100 MPa 15,000 psi (100 MPa)
Weight

3.650 | 3.700 | 3.800 kg 8,050 | 8,160 | 8,380 lb
Pick box

PH 32 HD Type PH 32 HD Type
Number of picks in cutter drums

44 | 48 | 56 Pcs 44 | 48 | 56 Pcs
Number of picks in the cutter chain

63 Pcs 63 Pcs
Standard pick

ER 17/75/70/30 Q ER 19/75/70/30 Q
