EK Chain Cutters

Model EK 110

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight

25 – 32 t 55,000 – 70,000 lb
Rated power

110 kW 147 hp (110 kW)
Drum cutter length (A)

1.970 mm 78 in
Cutter head width (B)

600 | 700 | 800 mm 24 | 28 | 32 in
Cutter drum diameter (C)

800 mm 32 in
Width of gearbox (D)

565 mm 22 in
Recommended rotation speed

65 rpm 65 rpm
Recommended oil flow

210 – 260 l/min 56 – 69 gal/min
Max. oil flow

300 l/min 80 gal/min
Max. operating hydraulic pressure

400 bar 5,800 psi (400 bar)
Max. torque at max. hydraulic pressure

24,500 Nm 18,070 lbf·ft
Max. cutting force at max. torque

61.3 kN 13,780 lbf
Max. uniaxial compressive strength

80 MPa 12,000 psi (80 MPa)
Weight

2.450 | 2.510 | 2.620 kg 5,400 | 5,535 | 5,775 lb
Pick box

PH 32 HD Type PH 32 HD Type
Number of picks in cutter drums

28 | 40 | 48 Pcs 28 | 40 | 48 Pcs
Number of picks in the cutter chain

54 Pcs 54 Pcs
Standard pick

ER 17/75/70/30 Q ER 17/75/70/30 Q
