DMW Cutter Wheels

Model DMW 220 Wheel 1000

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight
45 – 60 t 100,000 – 132,000 lb
Rated power
220 kW 295 hp (220 kW)
Cutting width (A)
130 | 200 | 400 mm 5 | 8 | 16 in
Cutting depth (B)
1.000 mm 40 in
Cutting depth with sliding device
900 mm 36 in
Cutter wheel diameter
2,570 mm 100 in
Recommended rotation speed
30 rpm 30 rpm
Recomm. oil flow according to wheel diameter
350 – 600 l/min 92 – 160 gal/min
Max. oil flow at 50 bar
700 l/min 185 gal/min
Max. operating hydraulic pressure
400 bar 5,800 psi (380 bar)
Torque at 350 bar
65,317 Nm 48,175 lbf·ft
Cutting force at 350 bar
50.8 kN 11,420 lbf
Max. rebar diameter in re-enforced concrete *
30 mm 1.25 in
Max. uniaxial compressive strength
100 MPa 15,000 psi (100 MPa)
Weight of drive unit, approx.
2.750 kg 6,060 lb
Weight of cutter wheel, approx. **
2.250 kg 4,960 lb
Weight of dipping device, approx.
920 kg 2,030 lb
Weight of protection cover, approx.
180 kg 400 lb
Pick box
PH 32 HD Type PH 32 HD Type
Standard pick
ER 22/75/70/30 Q ER 22/75/70/30 Q

KEMROC can supply wheels to order for various cutting widths and depths. Within technical boundaries, cutter wheels can be made to order.

* To maintain the warranty, check with the manufacturer before use in re-enforced concrete containing larger diameter rebar.

** Cutter wheel weight depends on diameter and width.
